| Indoor | DXK21ZRA-WF1 | ||||
| Outdoor | DXC21ZRA-W | ||||
| Power source (Outdoor Unit) | 1 Phase 240V 50Hz | ||||
|
*Operation data
|
Nominal Capacity (Range)
|
Cooling T1 |
kW
|
6.3 (1.2~7.4) | |
| Heating H1 | 7.1 (0.8 ~9.2) | ||||
| Heating H2 | 7 | ||||
|
Power consumption
|
Cooling T1 |
kW
|
1.58 (0.2~2.5) | ||
| Heating H1 | 1.60 (0.16~2.8) | ||||
| Maximum power consumption | kW | 2.9 | |||
|
Running current
|
Cooling T1 |
A
|
6.7 | ||
| Heating H1 | 6.7 | ||||
| Inrush current, maximum current | A | 6.7, 14.5 | |||
| EER | Cooling T1 |
|
3.99 | ||
| COP | Heating H1 | 4.44 | |||
| Sound power level (JIS C9612) | Outdoor | dB(A) | 64 | ||
|
Sound pressure level (JIS C9612)
|
Indoor |
dB(A)
|
44-39-35-25 | ||
| Outdoor | 54 | ||||
|
Energy label (GEMS 2019)
|
HOT
|
Cooling |
|
4 | |
| Heating | 3.5 | ||||
|
AVERAGE
|
Cooling | 3.5 | |||
| Heating | 3 | ||||
|
COLD
|
Cooling | 4 | |||
| Heating | 2.5 | ||||
|
External dimensions (HxWxD)
|
Indoor |
mm
|
339x1197x262 | ||
| Outdoor | 640×800(+71)x290 | ||||
|
Net weight
|
Indoor |
kg
|
15.5 | ||
| Outdoor | 45 | ||||
|
Airflow
|
Indoor (Cooling) |
l/s
|
342-301-262-173 | ||
| Indoor (Heating) | 392-317-275-218 | ||||
|
Refrigerant (Type, amount, pre-charge length)
|
Quantity | kg | (R32) 1.25 | ||
| Pre charged to pipe length | m | 15 | |||
|
Installation data
|
Refrigerant piping
|
Liquid line |
mm
|
Ø6.35 | |
| Gas line | Ø12.70 | ||||
| Connection method | Flare connection | ||||
| Maximum pipe (one way) length | m | 30 | |||
| Max vertical height diff. between O.U. and I.U. | m | 20 ( O.U. above I.U. ) / 20 ( O.U. below I.U. ) | |||
| Standard accessories | Allergen clear filter , NOVAShield Nano filter (PM2.5), Built-in Wi-Fi | ||||
| Optional parts | Interface kit (SC-BIKN2-E) | ||||
| Demand response (AS4755) | Yes | ||||
| * Operation data are conducted in accordance with AS/NZS 3823 standard. For testing conditions please refer to Page xxx | |||||
